Concrete laser screed for sale uses a laser reference system to control the leveling process and maintain the required elevation across a concrete slab. Instead of relying entirely on traditional manual screeding, the machine uses laser guidance together with mechanical and hydraulic systems to improve surface consistency. For projects involving large floor areas, industrial slabs, warehouses, roads, yards, and other concrete surfaces, this technology can help operators work more efficiently and maintain the required flatness or slope.
If you are searching for a reliable concrete laser screed machine to boost floor construction efficiency and finish quality, our 3 tailored models (YG-L300, YG-L300A, YG-290W) fully cover different job site demands. These machines integrate top-tier laser control systems, robust power units, and durable structural design to help you achieve perfectly flat, high-strength concrete slabs while cutting down manual labor and shortening project timelines.
Parameters of Concrete Laser Screed for Sale
| Model | YG-CL300 | YG-CL300A | YG-ZP30 |
| Engine model | Briggs & Stratton 38E3/LONCIN/Honda 690 (optional) | Briggs & Stratton 38E3/LONCIN/Honda 690 (optional) | Yanmar 4TNV94L |
| Engine type | Gasoline, air-cooled 4-stroke, twin-cylinder engine | Gasoline, air-cooled 4-stroke, twin-cylinder engine | Diesel |
| Engine power | 22KW/30ps | 22.8KW/23ps/31ps | 35.5KW/48hp |
| Fuel capacity | 20L (operation time is about 8 hours | 20L (operation time is about 8 hours | 100L |
| Hydraulic oil capacity | 37L | 35L | 150L |
| Laser transmitter | Swiss Leica/Tower transmitter (optional) | Swiss Leica/Tower transmitter (optional) | Danfoss |
| Laser receiver | Swiss Leica/Tower receiver (optional) | Swiss Leica/Tower receiver (optional) | American Tempo |
| Laser system control effect | Plane, slope, double slope (three-dimensional) |
Plane, slope, double slope (three-dimensional) |
German Mopar |
| Laser system control method | Microcomputer laser scanning | Microcomputer laser scanning | Flat, inclined or double slope (3D) |
| Paving method | Hydraulic stirring cage paving | Hydraulic stirring cage paving | Microcomputer laser scanning |
| Vibration method/excitation force | Hydraulic vibration/2000N | Hydraulic vibration/2000N | Hydraulic Cage Paving |
| Vibration plate width | 2500mm | 3000mm | Hydraulic motor |
| Leveling thickness | 50-300mm | 60-300mm | Flip up and down for easy cleaning, left and right switching, blades made of highly wear-resistant material, more durable |
| Travel drive | Reducer motor integrated | Reducer motor integrated | 6000mm |
| Travel speed | 0-4Km/h (speed adjustable) | 0-4Km/h (speed adjustable) | 3100mm |
| Travel tire | Solid anti-skid and anti-puncture tires (optional wide tires) | Solid anti-skid and anti-puncture tires (optional wide tires) | 100-450mm |
| Body size | 3250x2850x1320mm | 3300x3460x1650mm | 4-8km/h 24m/min |
Three Main Models of Concrete Laser Screed for Sale
Our concrete laser screed product line includes two gasoline‑powered units and one heavy‑duty diesel unit. Every model keeps core laser leveling functions while differing in working width, power output, and continuous working capacity.
YG‑CL300 runs on a 22KW/30ps air‑cooled 4‑stroke twin‑cylinder gasoline engine. Its vibration plate width reaches 2500 mm, with adjustable leveling thickness from 50 mm to 300 mm. The 20‑liter fuel tank supports around 8 continuous working hours. This compact machine has overall dimension 3250×2850×1320 mm, suitable for sites with moderate working space.
YG‑CL300A upgrades engine power to 22.8 KW/31ps and expands vibration plate width to 3000 mm. Its leveling thickness ranges from 60 to 300 mm, and the machine body size is 3300×3460×1650 mm. It shares the same 20‑liter fuel capacity and 8‑hour runtime with YG‑CL300. It is the preferred option when you need wider paving width under gasoline power.
YG‑ZP30 is the heavy‑duty diesel version, equipped with 35.5 KW/48hp Yanmar 4TNV94L diesel engine. It comes with a large 100 L fuel tank and 150 L hydraulic oil capacity. The paving width is 3100 mm, and the leveling thickness covers 100‑450 mm. Travel speed can reach 4‑8 km/h. Its blades adopt high‑wear‑resistant material with a flip‑up‑and‑down design for easy cleaning, built for long-term heavy‑load construction tasks.
All three models adopt a reducer‑motor integrated travel drive, with travel speed adjustable from 0‑4 km/h for gasoline versions. Solid anti‑skid anti‑puncture tires are standard, and wide tires are available as optional accessories.
Functional Highlights of the Laser Concrete Leveling Machine
Every concrete laser screed for sale in our lineup is built with practical, high-performance features:
Multi-dimensional leveling capability: Supports plane, single slope, double slope, and 3D special-shaped ground leveling to meet complex drainage and terrain design requirements
Microcomputer laser scanning control: Real-time dynamic adjustment of the screed head, to eliminate cumulative leveling errors that occur with traditional manual formwork control
Hydraulic vibration system: Delivers powerful excitation force to compact concrete thoroughly, improving the density and overall strength of the finished floor by over 20% compared to manual paving
Adjustable paving thickness: Covers a 50 mm to 450mm working range, adapting to thin overlay repairs and thick industrial floor construction demands
Typical Application Scenarios for Concrete Laser Leveling
These concrete laser screeds for sale are ideal for a wide range of construction projects:
Large industrial workshops, automated warehouses and logistics distribution centers that require ultra-flat heavy-load floors
Underground parking lots and commercial plazas with strict slope drainage design requirements
Large shopping malls, exhibition centers and airport terminal concrete slab paving
Special projects that need 3D irregular ground leveling, such as stadiums and landscape hardscaping areas
Thick-layer concrete construction for road and bridge engineering using the high-power diesel YG-290W model
Purchase Guidance to Select the Laser Concrete Screed
When you look for concrete laser screed for sale, matching model selection directly influences your project profit. You need to evaluate your maximum concrete pouring thickness, required paving width, daily working hours, and whether you prefer a gasoline or diesel power source.
If you work mostly on medium‑scale commercial floors with 8‑hour daily working shifts, the YG‑CL300 or YG‑CL300A gasoline laser screed will be cost‑effective options. For heavy‑duty, long-term construction, thick concrete layers, and large‑area infrastructure projects, we recommend the YG‑ZP30 diesel concrete laser screed. Optional parts, including Leica laser units and wide tires, can be configured according to your job‑site conditions.
If you can send us your project parameters, including required working width, concrete thickness, and local power‑source preference. Our professional sales engineers will recommend the most suitable concrete laser screed solution for you. For more details, please contact us freely.
