Small shot blasting machine is usually used for cleaning, polishing, and increasing the roughness of the road surface. It removes impurities, aging layers, and dirt on the road surface by spraying abrasive particles, to achieve the purpose of improving the quality of the road surface and extending its service life. The road blasting machine is mainly composed of sandblasting gun, sandblasting head, dust suction system, dust collection box, motor, control system, etc. Move the pavement portable shot blaster to the road surface to be processed, turn on the machine, the sandblasting gun starts to spray abrasive particles, and the dust suction system sucks away the loose impurities and abrasive particles and concentrates them in the dust collection box. It is usually used for cleaning and processing reinforced concrete pavement, cement pavement, airport runways, parking lots, and other ground. It can quickly and efficiently remove aging, wear, and dirt on the road surface, improve the skid resistance and wear resistance of the road surface, and make the road surface smoother and more beautiful. A pavement shot blasting machine is a very practical piece of equipment when constructing and maintaining roads.
Small Shot Blasting Machine Parameter
Model |
YGFY-270 |
YGFY-550 |
YGFY-850 |
Work Width |
270mm |
550mm |
850mm |
Diameter of shot blast wheel |
200mm |
||
Work efficiency on concrete surface |
150㎡/h |
600㎡/h |
600㎡/h |
Work efficiency on steel plate surface |
50㎡/h |
80㎡/h |
100-160㎡/h |
Shot blaster motor power |
11kw |
2*11kw |
2*15kw |
Supporting dust collector |
Six-core automatic backflush vacuum cleaner |
Eight-core automatic backflush vacuum cleaner |
Twelve-core automatic backflush vacuum cleaner |
Walking speed |
0-30m/min |
5-25m/min |
5-25m/min |
Walking motor |
0.75kw |
0.75kw |
1.5kw |
Suggest the diameter of the steel shot |
1.2-1.8mm |
1.5-1.8mm |
1.5-1.8mm |
Dimension |
1*0.3*1.1m |
2.05*0.72*1.46m |
1.95*1.02*1.55m |
Weight |
150kg |
595kg |
700kg |
Advantages and Features of Road Shot Blasting Machine
1. Efficient cleaning: The road shot blasting machine can quickly clean and treat the road surface in a short time, improving construction efficiency.
2. Uniformity: The small shot shot blasting machine can evenly spray abrasives onto the road surface to ensure uniform treatment effects.
3. Protect the road surface: The shot-blasting particles sprayed out are small and will not cause damage to the road surface.
4. Improve road quality: Through shot blasting, the anti-skid performance, adhesion, improving flatness of the road surface, and the service life of extending the road surface.
5. Environmental protection and energy saving: The dust collector recycles the shot and impurities to achieve the recycling of the shot, reducing waste and pollution.
