Water drilling equipment for sale refers to a range of machines designed to create boreholes and wells for extracting groundwater. These machines vary from portable rigs for shallow wells to massive hydraulic systems used in deep borehole drilling. They typically include components such as the drill bit, drill pipe, mud pump, rotary table, and power unit, all working together to penetrate soil and rock layers.
Parameters of the Water Drilling Equipment for Sale
| Model | YG-150 | YG-200 |
| Max Drilling Depth | 150m | 200m |
| Hole Diameter | Φ130-254mm | Φ130-254mm |
| Drilling Pipe Diameter | Φ76/89mm | Φ76/89mm |
| Drilling Pipe Length | 3m | 3m |
| Rig Lifting force | 12Ton | 15Ton |
| Rotating torque | 3500-3800Nm | 4000-4600Nm |
| Rotating speed | 40-65r/min | 45-65r/min |
| Engine power Diesel | 42KW | 58KW |
| Working air pressure | 1.7-2.5MPa | 1.7-2.5MPa |
| Air consumption | 17-31m3/min | 17-31m3/min |
| Dimensions | 3500*1700*2250mm | 3800*1700*2250mm |
| Weight | 4500kg | 4500kg |
Components and Their Functions
Every water drilling equipment for sale consists of several essential parts that determine its efficiency and performance.
Drill Bit: Cuts through soil or rock layers. Bits come in various designs for different formations.
Drill Pipe: Connects the drill bit to the surface equipment, transmitting rotation and pressure.
Power Unit: Provides the energy, usually via a diesel engine or electric motor.
Mud Pump: Circulates drilling fluid to cool the bit and carry cuttings to the surface.
Hoisting System: Lifts and lowers the drill string using a winch or hydraulic cylinders.
Control Panel: Manages operation parameters like speed, pressure, and fluid flow.
Advantages of Modern Water Drilling Equipment
High Penetration Speed: Advanced hydraulic and pneumatic systems allow fast drilling even in hard rock formations.
Precision and Stability: Digital control panels enhance accuracy and minimize deviation.
Energy Efficiency: Modern rigs use optimized power systems to reduce fuel consumption.
Versatility: Capable of adapting to diverse geological conditions.
Low Maintenance: Improved materials and design extend equipment lifespan.
How to Choose The Right Water Drilling Equipment for Sale?
When purchasing water drilling equipment, several factors must be evaluated.
Depth Requirement: Choose rigs that can reach the intended water table depth.
Formation Type: Hard rock demands DTH or rotary rigs, while soft soils work well with augers.
Mobility Needs: For rural projects, trailer-mounted or portable rigs are ideal.
Power Source: Diesel-powered rigs offer higher torque, while electric systems are cleaner and quieter.
